CS130 High Output Alternator - One Wire Turn On
CS130 High Output Alternator - One Wire Turn On - 320 amps 6 phase hairpin is backordered and will ship as soon as it is back in stock.
Couldn't load pickup availability
Subscribe to our newsletter
Sign up for exclusive offers.
CS130 High Output Alternator - One Wire Turn On
Description
Description
Hairpin units are commonly called 6 phase. They produce more output at idle and are more efficient than a conventional alternator. JS Alternators hairpin units feature premium bearings to withstand high engine rpm and utilize dual plate rectifier with 12 heavy duty diodes for improved cooling. Hairpin Units are a more reliable alternator to withstand high heat, high demand for car audio, marine, and racing applications.
This CS130 style alternator is commonly used on 1987-1995 Chevy C1500 Pickups and some aftermarket accessory drives. This unit makes for a super easy installation! To activate the alternator, you only need to connect a single wire from the provided pigtail to any ignition switched 12V+ source. This allows the alternator to turn on and off with the ignition switch. These units come with a smaller pulley which requires installing a half inch to an inch shorter belt.
All Motor Swap Applications will come with a 45 mm. pulley and will require installing a 1/2 inch - 1 inch shorter belt.
FITMENT GUIDE:
| Make | Model | Engine Size | Year |
|---|---|---|---|
| Buick | Roadmaster | 5.0L / 5.7L | 1991 - 1993 |
| Chevrolet | Astro Van | 4.3L | 1987 - 1995 |
| Chevrolet | Camaro | 5.0L / 5.7L | 1988 - 1992 |
| Chevrolet | Full Size Truck | All Gas Engines | 1987 - 1995 |
| Chevrolet | S-10 / S-10 Blazer | 4.3L | 1998 - 1993 |
| Chevrolet | Suburban | All Gas Engines | 1987 - 1995 |
| Chevrolet | Tahoe / Full Size Blazer | All Gas Engines | 1987 - 1995 |
| GMC | Full Size Truck | 4.3L | 1987 - 1995 |
| GMC | Full Size Truck | 5.0L | 1987 - 1995 |
| GMC | Full Size Truck | 5.7L | 1989 - 1995 |
| GMC | Safari | 4.3L | 1990 - 1993 |
| GMC | Suburban | All Gas Engines | 1987 - 1995 |
| GMC | Yukon | All Gas Engines | 1987 - 1995 |
| Oldsmobile | Bravada | 4.3L | 1991 - 1993 |
| Pontiac | Firebird | 5.0L / 5.7L | 1988 - 1992 |
